BLOWHARD SQUIRT - 17" HIGH-PERFORMANCE FAN
The BlowHard SQUIRT is an extremely compact, battery-powered high-performance fan that is suitable for military and tactical situations where mobility, rapid availability, and high impact in confined spaces are crucial. It has been designed so that it can be carried, positioned, and operated by individual personnel—even when wearing personal protective equipment or in dynamic combat situations.
Within the BlowHard system family, the SQUIRT serves as an ultra-compact, lightweight, and highly maneuverable air delivery device. Despite its minimal dimensions, it delivers an airflow that is usually only available from significantly larger and heavier systems. This makes the SQUIRT particularly suitable for use in confined structures, underground spaces, vehicles, containers, or winding buildings, as well as a targeted supplement to more powerful, stationary fans.
Thanks to its exceptional combination of airflow and energy efficiency, the SQUIRT can not only supplement larger systems in certain phases of operation, but also replace them in specific cases. This gives tactical units a considerable advantage when space, weight, or transport capacity are limited.
Note: The BlowHard Squirt is available in red as standard. On request, it can also be customized/painted in a special color by Vogt-CTE for orders of 50 units or more.
WHAT SETS OUR PRODUCTS APART
The integrated Smart-Tec system supports the operator with precise control and transparent status information about the current operating condition. Emergency personnel receive all relevant data in real time, enabling them to adapt the fan precisely to the tactical situation at hand. This allows for controlled, predictable airflow even under time pressure and stress.
The high performance of the SQUIRT is based on the so-called BlowHard Design Trifecta, consisting of three coordinated core technologies: High-Flow Jet Technology, the Ergo-Fold Alignment System, and the Opti-Max Efficiency Concept. These three principles have been specifically combined to enable maximum air delivery with minimum space requirements and low weight. The result is a tactical air delivery device with exceptional power density.
The integrated Smart-Tec high-performance battery ensures a reliable power supply for both short-term high-performance phases and longer, self-sufficient operations. Power output remains stable and predictable, which facilitates operational planning and reduces unplanned downtime.
High-flow jet technology ensures that the airflow generated is significantly stronger and more effective in terms of range than the size of the device would suggest. This allows the SQUIRT to deliver air over a distance in a targeted manner, displace contaminated or polluted air, and effectively supply fresh air without compromising mobility.
The Smart-Tec control system continuously monitors and visualizes all key operating parameters. These include remaining battery life, current thrust, and current air flow rate. These values adapt dynamically to the selected power level and provide the operator with a clear and reliable picture of efficiency, reserves, and energy consumption at all times.
All in all, the BlowHard SQUIRT is not a classic fan, but a highly mobile, tactical air management system that allows military units to control air, visibility, and temperature in a targeted manner, even under cramped, dangerous, or time-critical conditions.
BLOWHARD SQUIRT - TECHNICAL DATA
| Parameter | Value |
|---|
| Rotor Diameter | 432 mm – 17″ |
| Dimensions | 451 mm × 460 mm × 267 mm |
| Weight | 17.7 kg – 38 lbs |
| Direct Airflow | 19,028 m³/h – 11,200 CFM (AMCA equivalent) |
| Battery Type | Li-Ion |
| Runtime | Over 55 minutes at 19,028 m³/h – 11,200 CFM |
| Runtime | Over 6 hours at 10,194 m³/h – 6,000 CFM |
| Charging Time | 0% – 90% in 2 hours |
| Charging Time | Full charge in 3 hours |
| Battery Lifetime | Up to 1,000 full charge cycles (industry standard) |
| Dual Power Supply | Battery or AC operation |
| Power Switching | Seamless automatic switching between power sources |
| Dust and Water Protection | IP67 |
| Noise Level | 82 dB at 3 m – 10 ft |
| Fan Tilt | 0–180 degrees – stepless adjustment |
| Battery Capacity Indicator | Integrated |
| LED Ambient Light | Adjustable angle |
| Warranty | 2 years |
COMPLIES WITH DIN 14963
BlowHard firefighting fans have been extensively tested and fully comply with the current DIN 14963 standard for portable ventilation devices. This guarantees the highest quality, safety, and reliability in professional use.
THE INTELLIGENT DISPLAY ON THE DEVICE
- Real-time data display / Dynamic feedback
When adjusting the power, the display immediately shows values such as airflow (CFM), thrust, remaining runtime, and battery level. This means that the operator always has up-to-date information about the situation. - Intelligent system (“Smart-Tec”) with integrated control and diagnostics
The control panel is part of a comprehensive system that integrates battery management (charging, cell balancing, etc.) and diagnostic functions in addition to the display.- The system detects error conditions and provides data for error diagnosis.
- It manages charging cycles, cell balancing, and automatically protects the battery when connected to shore power.
- User-friendliness, transparency, and on-site control
The display eliminates the need for guesswork and estimation—the operations manager or operator can make decisions directly based on the visible parameters (e.g., how much power is needed, how long the battery will last). - Integration into a compact system
Although the device is relatively small and compact, the control panel and intelligence are seamlessly integrated without the need for external add-on modules.
PERFORMANCE DATA BLOWHARD SQUIRT
| Operating Mode | Runtime (minutes) | Airflow | Thrust | Noise Level |
|---|
| MAX Power | 55 | 11,200 CFM (≈ 19,029 m³/h) | 7.05 lbs (3.20 kg) | 88 dB @ 1 m |
| @1-Hour | 60 | 10,700 CFM (≈ 18,176 m³/h) | 6.36 lbs (2.89 kg) | 87 dB @ 1 m |
| @10,000-CFM | 74 | 10,000 CFM (≈ 17,010 m³/h) | 5.63 lbs (2.56 kg) | 85 dB @ 1 m |
| @7,500-CFM | 175 | 7,500 CFM (≈ 12,739 m³/h) | 3.16 lbs (1.44 kg) | 79 dB @ 1 m |
WHAT MODERN DEFENSE OPERATIONS NEED TODAY
POWER-TRONIC – Self-sufficient energy availability under operational conditions
POWER-TRONIC provides military units with intelligent energy management that is specially designed for use under time pressure and without logistical depth. The integrated charging system allows the fan to be connected directly to available AC power sources, such as in field camps, vehicles, buildings, or temporary bases. Separate chargers are no longer necessary.
The intelligent thermal management system continuously monitors the condition of the battery cells, automatically balances them, and protects the system from thermal overload. This ensures that the device remains reliably operational even during repeated or prolonged use.
Tactical advantages for military units
Immediate operational readiness without additional charging infrastructure
- Reduced logistical effort during deployment and use
- High operational reliability even under continuous load
- Minimized risk of failure in critical phases of operation
POWER-TRONIC thus particularly supports units that need to operate independently, mobile, and under changing conditions.
HIGH-CAPACITY BATTERY SYSTEM – Endurance without loss of performance
The High-Capacity Battery System is designed for maximum endurance with consistent power output. The large-format high-performance batteries deliver their energy evenly and stably, avoiding voltage fluctuations and thermal peaks.
This constant energy supply is a decisive advantage, especially in tactical scenarios where fans have to be operated for long periods of time.
Tactical advantages for military units
- Longer operating times without loss of performance
- High reliability during continuous operation
- Reduced risk of system shutdowns due to overheating
- Lower replacement and maintenance requirements in the field
The system increases the endurance of units, especially for ventilation tasks in large or complex areas of operation.
AIR-FLOW – Maximum effect with minimum energy consumption
The AIR-FLOW system is designed for maximum air movement efficiency. Optimized fan wheels and specially developed ventilation grilles ensure that motor power is converted into usable airflow with virtually no loss.
Flow losses and turbulence are minimized in a targeted manner, which reduces energy consumption while enabling high pressure and volume performance.
Tactical advantages for military units
- Rapid removal of smoke, dust, or heat
- Improved visibility in combat and operational areas
- Effective temperature reduction in buildings and structures
- Extended battery life with consistent performance
This is particularly relevant for long-term operations or missions without reloading options.
SMART-TEC – Digital overview of the air management situation
SMART-TEC acts as a digital control system and provides emergency personnel with a clear picture of the fan’s operating status at all times. Relevant parameters such as air flow rate, thrust, battery level, and remaining runtime are displayed in real time.
This transparency allows for precise tactical control and prevents wrong decisions due to uncertainty about system reserves.
Tactical advantages for military units
- Clear basis for decision-making during ongoing operations
- Better planning of mission duration and equipment use
- Reduction of risk through early status information
- Higher operational safety under combat conditions
SMART-TEC supports both commanders and operators in the controlled use of the system.
HIGH-FLOW-JET – Controlled airflow over distanc
HIGH-FLOW-JET technology enables a powerful, directed airflow with a long range. The special jet shape draws in ambient air, increasing the air volume and effect without additional energy requirements.
The air pressure remains stable both in the immediate vicinity and at greater distances, allowing for tactical flexibility in positioning.
Tactical advantages for military units
- Flexible positioning of the device outside danger zones
- Effective pressure sealing at access points and openings
- Reliable ventilation even in complex building structures
- Consistent effect regardless of installation distance
This is particularly advantageous when operating in unstable, contaminated, or hazardous environments.
OPTI-MAX – High performance with minimal logistical burden
OPTI-MAX describes the interplay of compact design, optimized airflow, and efficient energy use. This allows even smaller devices to achieve airflow rates that are otherwise reserved for significantly larger systems.
Tactical advantages for military units
- Can be used in confined spaces such as stairwells, basements, or vehicles
- Longer operating time thanks to energy-efficient operation
- Quick loading and easy transport
- Reduced space requirements in vehicles and containers
OPTI-MAX is particularly useful for mobile units with limited storage space and high frequency of use.
ERGO-FOLD – Quick adaptation to changing operational situations
ERGO-FOLD allows stepless adjustment of the fan’s angle of inclination up to 180 degrees, without tools and without loss of time. The air flow can be precisely adapted to terrain, buildings, or tactical requirements.
- Operation is easy even when wearing gloves or under stress.
- Tactical advantages for military units
- Quick adaptation to different areas of operation
- Optimal airflow even in difficult access situations
- Increased effectiveness through precise alignment
- Safe and easy operation under operational conditions
ERGO-FOLD increases tactical flexibility and reduces delays in device positioning.
